This Specification covers the requirements for siliconwafers for use in photovoltaic (PV) solar cell manufacture. To permit commonprocessing equipment to be used in multiple fabrication lines, it is essentialfor the wafer dimensions to be standardized.

This Specification provides standardized dimensional andcertain other common characteristics of silicon wafers based on currentlywidely used sizes for photovoltaic applications.

This Specification also provides a tabular specificationformat for order entry so that relevant non-standardized wafer characteristicsand extensions of wafer sizes for research, development, and new requirementscan be easily and consistently specified in commercial transactions.

This Specification covers ordering information and certainrequirements for single crystal silicon wafer and cast silicon wafer for PVapplications.

This Specification allows growth methods that includeCzochralski (Cz) method, Floating Zone (FZ) method for single crystal siliconwafers, and casting method with and without seed for cast silicon wafer.

The specified cast silicon wafer includes cast siliconcategory I wafer and cast silicon category II wafer.

A complete purchase specification requires that variousphysical properties be specified along with test methods suitable fordetermining their magnitude. The specification format in this Standard providesa comprehensive listing of such properties and available associated testmethods (see Appendix 1).
